Description
A high-performance Micro-ATX motherboard built with Intel’s B860 chipset and LGA 1851 socket.
It’s designed for Intel Core Ultra Series 2 processors, delivering next-gen connectivity like PCIe 5.0, Thunderbolt 4, Wi-Fi 7, and 5G LAN.
Optimized power delivery, advanced cooling solutions, and a wide range of I/O options make it ideal for gamers and content creators.
Key Features
- LGA 1851 socket with Intel B860 chipset for Intel Core Ultra Series 2 CPUs.
- DDR5 support up to 256 GB with speeds up to 8600+ MT/s.
- PCIe 5.0 x16 slot for high-performance GPUs.
- Three M.2 slots with PCIe 5.0 and PCIe 4.0 support.
- Killer BE1750x Wi-Fi 7 and Bluetooth 5.4 with low-latency networking.
- Killer E5000 5Gb LAN for ultra-fast wired connections.
- Thunderbolt 4 with 40Gbps data transfer, daisy-chaining, and 8K display support.
- Extended heatsinks and M.2 Shield Frozr II for cooling.
- EZ Debug LEDs, RGB/ARGB headers, and user-friendly assembly features.
- Micro-ATX form factor for compact, powerful builds.
Specifications
| Category | Details |
|---|---|
| Chipset | Intel B860 |
| CPU Support | Intel Core Ultra Series 2 |
| Socket | LGA 1851 |
| Form Factor | Micro-ATX |
| Memory Slots | 4 × DDR5 UDIMM, up to 256 GB |
| Memory Speed | DDR5 8600+ (OC), 6400–4800 (JEDEC), Intel XMP 3.0 |
| PCIe Slots | 1 × PCIe 5.0 x16, 1 × PCIe 4.0 x16, 2 × PCIe 4.0 x1 |
| Storage | 3 × M.2 (1 × PCIe 5.0, 2 × PCIe 4.0), 4 × SATA 6G |
| Networking | Killer E5000 5Gb LAN, Killer BE1750x Wi-Fi 7, Bluetooth 5.4 |
| Audio | Realtek ALC897, 7.1-Channel HD Audio |
| USB (Rear) | Thunderbolt 4, USB 5Gbps/10Gbps (Type-A, Type-C) |
| USB (Front) | Multiple USB 5Gbps/10Gbps ports, USB-C 10Gbps |
| Power Delivery | 12 Duet Rail Power System, high-efficiency P-PAK design |
| Cooling | Extended heatsinks, M.2 Shield Frozr II |
| Lighting | 2 × ARGB V2, 1 × RGB headers |
| Diagnostics | EZ Debug LEDs |
