Description
The ASUS Prime RTX 5060 Ti OC is a PCIe 5.0 graphics card powered by NVIDIA’s latest Ada Lovelace architecture. Designed for 1080p and 1440p gaming, this card features 8GB of high-speed GDDR7 memory, a triple-fan cooling system, and factory-overclocked performance. Ideal for gamers and creators needing DLSS 4 and ray tracing acceleration at a balanced price point.
Key Features
- Overclocked boost clock up to 2647MHz for peak performance
- 8GB GDDR7 VRAM at 28Gbps with 128-bit bandwidth
- Supports up to 4 monitors with HDMI 2.1b and DisplayPort 2.1b
- Powered by NVIDIA Ada Lovelace architecture with 4608 CUDA cores
- AI performance rated at 772 TOPs with DLSS 4
- Triple axial-tech fan design with 0dB technology for quiet cooling
- ASUS GPU Tweak III software included
Technical Specifications
| Specification | Details |
|---|---|
| Model | PRIME-RTX5060TI-O8G |
| GPU Engine | NVIDIA GeForce RTX 5060 Ti |
| AI Performance | 772 TOPs |
| Bus Standard | PCI Express 5.0 |
| OpenGL Version | 4.6 |
| Video Memory | 8GB GDDR7 |
| Memory Speed | 28 Gbps |
| Memory Interface | 128-bit |
| CUDA Cores | 4608 |
| Engine Clock | OC: 2647 MHz / Default: 2617 MHz |
| Max Resolution | 7680 x 4320 (8K) |
| Display Outputs | 1× HDMI 2.1b, 3× DisplayPort 2.1b |
| HDCP Support | Yes (2.3) |
| Multi-Display Support | Up to 4 displays |
| NVLink / SLI | Not supported |
| Slot Size | 2.5 Slot |
| Power Connector | 1× 8-pin |
| Recommended PSU | 550W |
| Dimensions | 304 x 120 x 50 mm |
