Description
The ROG STRIX Z890-A GAMING WIFI is a high-performance ATX motherboard built for Intel Core Ultra Series 2 processors. With full support for DDR5 9066+ MT/s, PCIe 5.0, Wi-Fi 7, and dual Thunderbolt 4, it’s engineered for gamers and creators needing reliable performance and future-ready features. It includes extensive cooling support, robust power delivery, premium audio, and smart installation tools.
Key Features
- Intel® LGA1851 socket for Core™ Ultra Series 2 CPUs
- DDR5 memory support up to 256GB at 9066+ MT/s (OC)
- 1× PCIe 5.0 x16 slot, 5× M.2 slots (PCIe 5.0/4.0)
- Dual Thunderbolt™ 4 ports and HDMI/DisplayPort outputs
- Wi-Fi 7 (802.11be) and Intel® 2.5Gb LAN
- SupremeFX 7.1 audio with ALC4080 codec and premium amp
- Q-Design features for tool-less building and upgrades
- AURA Sync with Gen2 ARGB headers
Technical Specifications
| Feature | Details |
|---|---|
| CPU Support | Intel® Core™ Ultra (Series 2), LGA1851 |
| Chipset | Intel® Z890 |
| Memory | 4× DDR5 DIMM slots, up to 256GB, 9066+ MT/s OC, XMP, AEMP III, DIMM Flex |
| Expansion Slots | 1× PCIe 5.0 x16, 1× PCIe 4.0 x16 (x4 mode) |
| Storage | 5× M.2 (1× PCIe 5.0, 3× PCIe 4.0, 1× PCIe 4.0 + SATA), 4× SATA 6Gb/s |
| Integrated Graphics | 1× HDMI 2.1, 1× DisplayPort 1.4, 2× Thunderbolt 4 (DisplayPort via Type-C) |
| LAN | Intel® 2.5Gb Ethernet with ASUS LANGuard |
| Wireless | Wi-Fi 7 (2×2, 2.4/5/6GHz, 320MHz), Bluetooth 5.4 |
| Rear USB | 2× TB4 (Type-C), 6× USB 10Gbps (5× A + 1× C w/ 30W PD), 2× USB 5Gbps (A) |
| Front USB | 1× USB 20Gbps (C), 2× USB 5Gbps (via header), 4× USB 2.0 (via headers) |
| Audio | ROG SupremeFX ALC4080, 7.1ch, 120 dB SNR, Savitech AMP, S/PDIF |
| Cooling Headers | 1× CPU, 1× CPU OPT, 1× AIO, 5× Chassis Fan (4-pin) |
| Power Connectors | 24-pin ATX, 2× 8-pin CPU 12V |
| RGB Headers | 3× Addressable Gen2 ARGB |
| Special Features | Q-Latch, Q-DIMM, BIOS FlashBack™, Clear CMOS, FlexKey, AI Cooling II |
| Form Factor | ATX (30.5 × 24.4 cm) |
