Description
The TUF GAMING Z890-PRO WIFI motherboard blends military-grade durability with modern performance for Intel® Core™ Ultra Series 2 CPUs. Built with PCIe 5.0, DDR5 support up to 9066+?MT/s, 4× M.2 slots, Thunderbolt 4, and Wi-Fi 7, this board is ideal for builders prioritizing stability, long-term reliability, and next-gen gaming or productivity performance.
Key Features
- Supports Intel® Core™ Ultra Processors (Series 2) on LGA1851
- PCIe 5.0 x16 slot for GPUs + 4× M.2 slots including PCIe 5.0
- Up to 256GB DDR5 @ 9066+ MT/s with XMP and AEMPIII support
- Dual Thunderbolt™ 4 ports, DisplayPort, and HDMI 2.1 output
- Intel® 2.5Gb LAN + Wi-Fi 7 (up to 2.9Gbps), Bluetooth 5.4
- Realtek ALC1220P 7.1 HD Audio with optical S/PDIF
- Reinforced PCIe SafeSlot, stainless-steel I/O, TUF capacitors
- Aura Sync Gen2 headers and USB 20Gbps front Type-C with 30W PD
Technical Specifications
| Feature | Details |
|---|---|
| CPU Support | Intel® Core™ Ultra (Series 2), LGA1851 |
| Chipset | Intel® Z890 |
| Memory Support | 4× DDR5 DIMMs, up to 256GB, 9066+ MT/s OC, XMP, AEMPIII |
| Expansion Slots | 1× PCIe 5.0 x16, 1× PCIe 4.0 x16 (x4), 1× PCIe 4.0 x4, 2× PCIe 4.0 x1 |
| Storage | 4× M.2 (1× PCIe 5.0, 2× PCIe 4.0, 1× PCIe 4.0/SATA), 4× SATA 6Gb/s |
| Integrated Graphics | 1× HDMI 2.1, 1× DisplayPort 1.4, 2× Thunderbolt 4 (DP via USB-C) |
| LAN | Intel® 2.5Gb Ethernet with TUF LANGuard |
| Wireless & BT | Wi-Fi 7 (160MHz, 2.9Gbps), Bluetooth 5.4 |
| Rear USB Ports | 2× TB4 (USB-C), 6× USB 10Gbps (Type-A) |
| Front USB Ports | 1× USB 20Gbps Type-C (30W PD), 2× USB 5Gbps, 4× USB 2.0 |
| Audio | Realtek ALC1220P 7.1 Surround, Optical S/PDIF, 120 dB SNR |
| Cooling Headers | 1× CPU, 1× CPU OPT, 1× AIO, 4× Chassis Fan |
| Power Connectors | 24-pin ATX, 2× 8-pin CPU 12V |
| RGB Headers | 3× Addressable RGB Gen 2 |
| Special Features | TUF Protection, Q-Latch, Q-Release, BIOS FlashBack™, DTS Audio |
| Form Factor | ATX (30.5 × 24.4 cm) |
