The Geometric Future Model 8 Cowboy is a premium mid-tower case built for enthusiasts who demand high-end performance, advanced airflow, and a clean, professional look.
Crafted from 1.0mm steel with a 4.0mm tempered glass side panel, this case offers durability, visibility, and flexibility for both air and liquid cooling builds.
It supports E-ATX motherboards, full-length GPUs, and multiple radiator configurations, making it ideal for gaming or workstation setups that combine power and style.

Key Features

•  Premium Construction – Durable 1.0mm steel frame with 4.0mm tempered glass panel
•  Spacious Interior – Supports large components including GPUs up to 412mm and PSUs up to 220mm
•  High Cooling Flexibility – Supports 360mm, 420mm, and 280mm radiators for extreme cooling performance
•  Modern Connectivity – Includes USB Type-C (USB 3.1 Gen 2), 2× USB 3.0, 2× USB 2.0, and HD Audio (CTIA) ports
•  Flexible GPU Mounting – Horizontal and vertical mounting options with full airflow clearance
•  Advanced Airflow Design – Supports up to 9 fans for superior heat dissipation
•  Elegant Black Finish – Stylish and professional look with clear tempered glass window

Technical Details

•  Case Type: Mid Tower
•  Material: Steel (1.0mm), Tempered Glass (4.0mm)
•  Color: Black
•  Dimensions (H × W × D): 500 × 230 × 500mm (19.7″ × 9.1″ × 19.7″)
•  Drive Bays:
  • Max: 3×3.5″
  • 3×2.5″ / 6×2.5″ tray
•  Motherboard Compatibility:
  • E-ATX (12″×13″)
  • ATX, Micro-ATX, Mini-ITX
•  Power Supply Support:
  • ATX 12V (Length < 220mm)
•  Expansion Slots:
  • PCI-E ×7: Length < 400mm (no bottom cooling) / Width < 175mm
  • Lateral PCI-E ×3: Length < 412mm / Width < 150mm / Height < 65mm
  • CPU Cooler Height < 105mm
• Cooling Support:
•  Top: 120mm fan ×1 / 120mm radiator (optional)
•  Rear: 120/140mm fan ×3 / 420mm radiator (L<470mm / T<55mm)
•  Front: 360/280mm radiator (L<400mm / T<65mm)
•  Bottom: 120/140mm fan ×3 / 360/280mm radiator (L<485mm)
•  CPU Heatsink Height: <170mm
•  I/O Ports:
  • 2× USB 3.0
  • 2× USB 2.0
  • 1× Type-C (USB 3.1 Gen 2)
  • 1× HD Audio (CTIA-SPK/MIC)

User Benefits

•  Perfect for Enthusiasts: Designed for builders who want performance, cooling, and aesthetics in one chassis
•  Next-Gen Connectivity: Front I/O ports include Type-C for high-speed data and power delivery
•  Clean Cable Management: Spacious layout ensures easy and organized assembly
•  Superior Airflow: Optimized ventilation and fan placement for consistent thermal balance
•  Elegant Presentation: Showcase your build through the tempered glass side panel

Included Items

• Geometric Future Model 8 Cowboy Case – Black
• Mounting Screws and Accessories
• Pre-installed Dust Filters
• Quick Installation Guide
